AR-2A Steiner 9041
DISCONTINUED
The AR-2A LASER w/Tactical Light Mount provides the utmost flexibility in critical situations.
This lightweight, waterproof unit is
equipped with a Red or Green LASER. Made of a lightweight and durable aluminum
alloy, the housing has a scratch and corrosion-resistant matte black anodized
finish and is submersible to 5'. Since the sight is designed for use on
rifles without rails, Steiner Optics outfitted the housing with dual side
Picatinny rails to mount lights or other smaller accessories.
Manufactured in
the USA using the finest quality
materials, with a 3 Year Warranty.
The AR-2A laser includes a sturdy
MIL-SPEC-1913 rail mount to accommodate our popular OPERATOR and OPERATIVE tactical lights or
other accessories depending on your mission requirements.
Available for M-4, M-16, and AR-15 rifles.
NO EXPORT
Features
* Rugged aerospace aluminum
housing, MIL-SPEC Type III Hardcoat anodized
* Accommodates M-203
equipped rifles with side sling mount
* Dual MIL-SPEC-1913 rails provides a sturdy mount for tactical lights
* Fully adjustable for Windage and Elevation
* Laser doesn't obscure iron sight
* Meets MIL-STD-810G for adverse environmental conditions
* No weapon modification required
* Low Parallax
* Reduces weapon weight--No Foregrip or barrel mounting bracket
required
* Waterproof to 5 Meters
Supplied with:
Dual MIL-SPEC-1913 rail for A-Frame Front Sight, Mounting Hardware, 1.5-Volt AA Battery:
AR-2A for M-4 includes a 6" remote cable pressure pad switch;
AR-2A for M-16 is supplied with a 8" remote cable pressure pad switch
Steiner Optics' AR-2A Red Laser Sight
is designed for use on rail-less rifles by clamping onto the front A-frame
iron sight. This durable compact laser aiming device features a 5 mW Class
IIIa red laser, and independent hand-adjustable windage and elevation turrets.
An integrated remote activation switch has double-sided tape for precise
placement based on your specific hold.
AR-2A™ Laser w/Tactical Light Mount | ||||
Laser Specifications | ||||
Visible Pointers | Infrared Pointer | |||
Type: | Laser Class IIIa |
Laser Class IIIb |
||
Power Output: | <5 mW |
<5 mW |
||
Wavelength: Red/Green | 635nm/532nm |
850nm |
||
Beam Diameter: | 8 mm at 25 m |
8 mm at 25 m |
||
Beam Divergence: Red/Green |
0.3 Millirads 0.5 Millirads |
0.8 Millirads |
||
Visibility Range: Night/Day Red/Green |
500m/10m 1500m/30m |
600 Meters |
||
Temperature Range: Red/Green |
-40˚C to +51˚C 0˚C to +45˚C |
-40˚C to +51˚C |
||
Battery Type / Life: | (1) AA Battery will typically last 5 hours continuous | |||
Mechanical Specifications | ||||
Material: |
Anodized Aircraft Aluminum 6061T-6 |
|||
Dim: in (w/Mount) | Length: 5.125 " | W: 1.5" | Height: 1.7" | |
Dimension: cm | Length: 13cm | W:13.8cm | Height: 4.3cm | |
Total Weight (oz./g) | 5.6 ounces |
159 grams |
||
Environment: |
Submersible to 5 Meters |
|||
Typical Weapon Types: | M-16, AR-15, and M-4 Rifles | |||
LDI Patent No.: | 5,581,898 | |||
Warranty: | 3 Years |
