DBAL-D2 Steiner 9001
DBAL-D2, PN: 9001(Black) & 9002(Tan) DISCONTINUED LASER
The powerful DBAL-D2 is power packed with a focus-able IR LASER illuminator, a Class 1 Eye-Safe Infrared Aiming LASER Pointer for use with Night Vision Devices, and a visible Green Ultra Power Point Aiming LASER pointer, which is five times more visible than traditional Red LASERS and the maximum allowed by law for maximum daytime visibility.
Dual Beam Aiming LASER:
Supplied with:
Quick Release HT Mount, Battery, (1) 3-Volt 123A Lithium Battery, 7" Right Angle Remote Cable
Pressure Pad Switch (Specify
cable length if different from standard)
* Integrated Momentary Remote Pressure Pad Switch & Activation Switch
* Single-Tap - Enables momentary activation
* Double-Tap - Instantly activates the LASER in a
5 Minute continuous "ON Mode".
* Built-in safety returns the unit to momentary activation after 5
minutes.
* The Pressure Pad provides a tactile (silent) click that indicates when
the switch has been activated
The powerful DBAL-D2 is power packed with a focusable IR LASER illuminator, a Class 1 Eyesafe Infrared Aiming LASER Pointer for use with Night Vision Devices, and a visible Green Ultra Power Point Aiming LASER pointer, which is five times more visible than traditional Red LASERS and the maximum allowed by law for maximum daytime visibility. When every second counts, the versatile DBAL-D2 is the right choice for any mission. Designed for maximum operational versatility while keeping the weight down and size to a minimum, the DBAL-D2 is Combat Ready and considered to be the most innovative and multi-functional LASER system on the market today.
The DBAL-D2 is the commercial version of its predecessor, the DBAL-A2. The DBAL-D2 is equipped with a visible laser pointer, Class 1 IR laser pointer, and a high definition, aspherical, telescopic IR LED illuminator that outperforms all other IR illumination devices.
The
DBAL-D2 feature a new streamlined housing, improved Windage and Elevation adjusters
and a single activation switch. Frequently compared to the plastic-molded AN/PEQ-15, the DBAL-D2 delivers
superior operational longevity due to its all metal housing and mounting
system.
Manufactured
in the USA using the finest quality materials, with a 3
Year Warranty.
EXPORT LICENSE
REQUIRED.
Features
* Rugged aerospace
aluminum housing
* MIL-SPEC Type III Hardcoat anodized
* Instantly switch between LASER
functions:
Visible Pointer only - IR Pointer only - IR Illuminator only
* Infrared Pointer & Infrared Illuminator combined
* Co-Aligned Visible & IR Aiming LASER's
* Single adjustment mechanism for both IR & Visible LASER's
* Hi-Power & Lo-Power (Class I) modes of operation
* 2° to 30° adjustable IR Illuminator
* Fully adjustable for Windage & Elevation for Pin-Point Accuracy
* Collimated IR illuminator enhances
Night
Vision performance
* Activation and Low Battery Indicator Light
* Meets MIL-STD-810F for adverse environmental conditions
* Mounts on all MIL-SPEC-1913 rails
* Positive On/Off Kill Switch prevents accidental activation
* Precision glass lens produces a virtually round laser point
* Waterproof to 20 Meters
LASER Type:
Visible Green - Class IIIa
IR LASER - Class I LED
IR Illuminator - Eye Safe
Visible Green Laser - Class IIIa 532nm
Beam Divergence: <0.8 mRAD
High Output: <5mW
Low Output: 1mW
Range/Visibility (Day) 15m (16yds)
Range/Visibility (Night) 750m (820yds)
Power Output:
IR LASER Pointer <0.7mW (non LED)
Beam Divergence: <0.8 mRAD
Wavelength: 850nm
Range/Visibility (Night): >250m (274 yards)
IR Illuminator: <600mW LED
Beam Divergence: 2° to 30°
Wavelength: 850nm
Range/Visibility (Night) ≤1000m (1100yds)
850nm Low Output: <300mW: Yes
High/Low Operation: Yes
Includes Pressure Pad Switch: Yes
Pushbutton Activation: Yes
Remote Cable Activation: Yes (Pressure Pad Switch)
Momentary On: Yes
Constant On: Yes
Windage/Elevation Adjustable: Yes
Quick Detachable HT Mount: Yes
Mounts to MIL-STD 1913 Picatinny: Yes
(1) CR123A Battery Operation: Yes
Battery Life: >3 Hours
Waterproof: Submersion in Meters: 5 meters
Weight in ounces: 8oz / Weight in grams: 227g
Size: Length = 3.5" (91.4 mm) / Width = 2.75" (69.9 mm) / Height = 1.59" (40.4 mm)
Aircraft Aluminum 6061-T6 w/Class III Hard Anodized Housing: Yes
Temperature Range: 40°C(-40°F) to +65°C(149°F)
Max Storage Temperature: 80°C (176°F)
Warranty in Years: 3 Years
Optional Accessories:
9103 (Old LDI PN: FA06883-01) Exit Port Cover - Visible/IR Pointer - Black
9105 (Old LDI PN: FA06883-03) Exit Port Cover - Visible/IR Pointer - Tan
9111 (Old LDI PN: FA05805-01) CR123A Battery Cap - Black
9112 (Old LDI PN: FA05805-03) CR123A Battery Cap - Tan
9113 (Old LDI PN: FA06393-01) CR23A Battery Cap STRAP (For 9111) - Black
9114 (Old LDI PN: FA06393-03) CR123A Battery Cap STRAP (For 9112) - Tan
9120 (Old LDI PN: FA05063-7) 7" Right Angle Remote Cable Pressure Pad Switch
9121 (Old LDI PN: FA05219-7) 7" Straight Remote Cable Pressure Pad Switch
9135 (Old LDI PN: FA05233-01) Set of 5 Optical Pattern Generators, IR Pointer - Black
9137 (Old LDI PN: FA05238-01) 80° Optical Diffuser - Black
9138 (Old LDI PN: FA05349-01) Neutral Density Filter, Dust Cover - Black
9145 (Old LDI PN: FA06146-01) Dual Remote Cable Pressure Pad Switch - Black
SYSTEM DESCRIPTION
The
DBAL-D2
is a Class IIIa laser device that features a Visible Pointer for daylight and
low light operations, as well as an Infrared Pointer and Infrared Illuminator
for use with Night Vision Devices. The IR beams
can be operated individually or in combination, in both low power (LO PWR) and
high power (HI PWR) settings.
The DBAL-D2 emits
a highly collimated beam of IR light for precise aiming of the weapon and a
separate IR Illuminator for the target or target area. The IR Illuminator is
equipped with an adjustable bezel to vary the size of the illumination beam
based on the size and distance to the target. The Visible Pointer and the IR
Pointer are co-aligned. The Visible Pointer can be used to boresight the
device without the requirement of a Night Vision Device
and will simultaneously boresight the IR Pointer.
The DBAL-D2 can
be used as either a handheld illuminator/pointer or it can be weapon mounted
using the Throw Lever Mount. In the weapon mounted mode, it can be used to
accurately direct fire as well as illuminate and identify targets.
When the Safety Screw is installed in the rear of the
DBAL-D2 housing, it
prevents the operator from accessing the, HI PWR modes of
operation.
DBAL-D2 Item Description
1) Battery Cap and Compartment
2) Infrared Illuminator
3) Throw Lever Mount
4) Visible Pointer
5) Boresight Adjusters
6) Infrared Pointer
