Zero Lens
*Please
call (702) 324-6463 or
email for Mil/LE Discounts*
Stand Alone Kit Includes: Zero Lens,
3X Lens, Quick-Disconnect Mount
for MIL-STD 1913 Rail,
Hard Case, Lens Cleaning Kit, Operator's Manual
PVS-14 Not Included in Kit (shown for information purposes only)
Optional Items:
Night Vision Monoculars (Thermal or Image Intensified)
FEATURES:
-
Non-Electric - Does NOT use Batteries
- MIL-STD 810F Compliant
- Quick-Disconnect Throw-Lever Mounting System, MIL-STD 1913 Rail
- Simple Elevation/Bearing Adjustments
- Conveniently Aligns to your Day Optics
- Robust, Compact Design
-
Maintains Consistent Eye-Relief
The Zero Lens™ is an optical alignment
adapter that enables the use of PVS-14 Night Vision Monocular in front of
day sights to add nighttime engagement capability with no zero shift. This
configuration is more efficient and user friendly than when the PVS-14 is
mounted behind the primary sight.
This passive system counters an enemy force’s ability to detect
active IR laser pointers and illuminators.
Image intensification efficiency of the PVS-14 is maintained by front mounting, and resolution of the produced image is improved as it passes through the Zero Lens™. Front mounting also allows the operator to maintain the same shooting position, muscle memory, and eye relief with his primary sight.
The
standard quick detach mounting system enables rapid installation and
removal, allowing easy transition of the PVS-14 between handheld, helmet
mounted, or weapon mounted use as needed during operations. Once set, the
Zero Lens™ will maintain alignment between the Day Sight and the adjusted
PVS-14 when it is re-installed.
The Zero Lens™ is a rugged, non-electronic,
compact device that adds capability to your existing inventory of optics at
a fraction of the cost of adding new stand alone systems.
Proudly manufactured in the USA
With the right mount (Tripod Type), Zero Lens™ can be used with Night Vision Monocular's such as:
- PVS-14
- PVS-18
- MUM-14
- Thermal PVS-14
...to add nighttime capability to:
- Electronic Sights
- Optical Scopes
- Video Camera
|
|
||
| Optics FOV | ||
| Optics FOV | 14°(w/3X Lens) | |
| f Number | 1.1 | |
| Optical Axis above Rail | 40mm (1.57") | |
| Azimuth Adjustments | 0.5 MOA/Click | |
| Elevation Adjustments | 0.5 MOA/Click | |
| Size w/Mount | 145 x 82 x 64 mm |
5.7 x 3.2 x 2.5 in |
| Weight w/Mount | 457g |
16.1 oz |
| Operating Temp | -51°C to +49°C |
-60°F to +120°F |
| Storage Temp | -51°C to +85°C |
-60°F to +185°F |
